Some of us learn best by reading. Others find they comprehend a subject better if they
can watch as it's being performed. For this reason, the best learning environment is
one where a subject can be approached in alternative ways. That way, we can learn by
the method or methods that work best for us as individuals.
With this
three-DVD set
, accomplished hand tool woodworker Paul Sellers offers a great
companion instructional method to accompany
his recent volume,
Essential
Woodworking Tools
. Beautifully filmed and carefully rehearsed, these DVDs give those
who are visual and audial learners a valuable resource for understanding what are the
essential tools, how to set them up, sharpen them and put them to use.
Sellers begins the first DVD with sharpening, starting with the kit he uses-- a set of three
diamond plates he lubricates with ordinary window cleaner. He mostly hones his blades
freehand and shows how any woodworker can do this. He finishes by honing on a grit-
charged strop, taking as many as 40-50 strokes with heavy pressure applied. You can
build the strop for yourself, and he shows you how.
His next major topic is planes. He shows how to refurbish a
Stanley No. 4
and make it
into a good user, first flattening the sole and sides, then knocking off the sharp edges
with a file. After disassembling the plane completely, he cleans the japanning and
hones the frog mating surfaces on his diamond plate. His example had a slight hollow
on the back of the blade, which he flattened with a hammer. Then, the hollow removed,
he flattens the back and front bevel on his diamond plate. He files off the
arrises—sharp edges—to reduce the chances of leaving tracking marks. He cambers
his blades by adding finger pressure to the sides of the blade while honing it. After
setting the primary and microbevels, he strops the blade using green honing grit.
Next come spokeshaves, especially the Stanley 151. Start by flattening the sole on the
diamond plate. Note that, unlike plane blades, the spokeshave sole need not be
completely flat. To finish, he flattens and sharpens the blade and the underside of the
cap iron.
Rabbet (rebate) planes are essential tools in his toolkit. So are plow planes. You want
a plow plane with a fence and a depth stop. The Record 044, a British make available
at used tool dealers or on eBay, fits these criteria. To put it to use, he polishes the
blade back and then hones the primary bevel. But there's no need to go overboard
here; these are very forgiving, he states.
Another essential tool is the router plane. He uses an old Stanley model, though
modern versions are also available. You can make a wooden base to fit the plane you
have, if needed. He shows how you can easily do this and enhance your hand tool
skills in the process.
The second DVD begins with layout tools, which are essential to producing quality work.
The
combination square
tops your list of needed tools. It must be accurate, so check it
periodically for accuracy; Sellers shows an easy way to do this. Other critical tools are
a
marking knife
and a sliding bevel gauge. Chisels and gouges, especially a quality set
of bench chisels, are also essential.
More time is devoted to the subject of
saws
, and Sellers demonstrates techniques for
using them, sharpening them and taking out excess set by hammering the blade against
another hammer.
Scrapers and abrading tools
are needed to attain a fine finish on wood and to create
curved shapes not easily achievable with other tools. These tools include rasps and
cabinet scrapers. Sellers shows how to hone and adjust a scraper plane blade and
card scraper, essential if they are to produce shavings rather than dust.
Boring and drilling tools are another important part of the woodworker's toolkit. Sellers
not only describes the tools but also shows how to sharpen the bits and how best to use
them. Also essential for marking drill locations, starting screw holes and even finishing
some tasks of boring is the birdcage awl, whose sharpened, four-sided shaft is ideal for
cutting into the width of the hole it creates. A mill file to sharpen drill bits and the awl is
also needed. The DVD concludes with a presentation on hammers.
The third DVD in the set is focused on using some of the tools previously identified.
The first of these is a simple graphite pencil—wooden, of course—and Sellers lays out
an angled bridle joint to demonstrate how to achieve accurate results, including how to
hold a combination square in use.
He uses a chisel and mallet to quickly cleave waste wood from the cheeks of the bridle
joint tenon. Gouges are used for curved work and embellishments, which Sellers
demonstrates by hollowing out the bowl of a spoon with a sharp gouge.
Planes can be used for rounding over as well as cutting chamfers and smoothing final
surfaces. Spokeshaves are excellent for rounding arrises and for other shaping
operations. Sellers shows why to always work the grain in a downhill direction. He
continues by demonstrating the plow plane and router plane.
Saws are next and Sellers shows sawing techniques, how to hold the saw and how to
start a cut without first pulling the blade to create a slight groove. He shows how you
can make a saw oiler from a small can, some rags and light oil. He demonstrates how
to use a coping saw.
Final topics include using a cabinetmaker's rasp to shape the body of a spoon before
finishing it with a file and scraper, boring through holes without tearout on either side
and putting mallets and hammers to work.
This DVD set is a good companion to his
recent book on the same subject
. Sellers
takes potentially daunting topics and makes them understandable and approachable.
His emphasis is on keeping things simple and he does just that for the viewer. Because
he focuses on the basics, this set will be most helpful to beginning woodworkers. It will
also appeal to those whose learning style is best accommodated by visual
presentations rather than reading. For these woodworkers, this DVD set will be a good
way to gain the basics of how to build and use an essential base of hand tools.
